Tube Tech manufactures and supplies Cupro Nickel Fin Tubes fin tubes with excellent dimensional control, mainly for corrosive atmosphere & sea applications. We manufacture Cupro Nickel Fin Tubes in both 90/10 & 70/30 metal combinations as per the requirements.
Cupro Nickel alloys exhibit excellent resistance to impingement attack. These alloys ares suitable for Marine Condenser Fin Tubes, especially where higher water velocities are encountered and offer best resistance to impingement attack and to corrosion from most acids and waters.
Cupro Nickel fin tubes are fabricated in alloy C 70600 / C 71500 to meet the chemical, mechanical and other test parameters of ASTM B 111 / B 359. BS EN, JIS and DIN standards are also available on request.
Tube Dia | Wall Thickness | Fin Density | Fin Dia | Fin Depth | Root Dia | Wall Thickness under Fins |
---|---|---|---|---|---|---|
19.05 mm | 2.11 mm | 19 / 26 / 40 | 18.80 mm | 1.52 mm | 16.10 mm | 1.30 mm |
19.05 mm | 1.65 mm | 19 / 26 / 40 | 18.80 mm | 1.35 mm | 16.10 mm | 1.00 mm |
19.05 mm | 1.32 mm | 19 / 26 | 18.80 mm | 1.1 mm | 16.60 mm | 0.75 mm |
19.05 mm | 1.24 mm | 19 / 26 / 40 | 18.80 mm | 1.1 mm | 16.60 mm | 0.65 mm |
15.87 mm | 2.11 mm | 19 / 26 | 15.70 mm | 1.35 mm | 13.00 mm | 1.30 mm |
15.87 mm | 1.65 mm | 19 / 26 | 15.70 mm | 1.25 mm | 13.20 mm | 1.00 mm |
15.87 mm | 1.47 mm | 19 / 26 | 15.70 mm | 1.25 mm | 13.20 mm | 0.90 mm |
15.87 mm | 1.32 mm | 19 / 26 | 15.70 mm | 1.1 mm | 13.50 mm | 0.75 mm |
15.87 mm | 1.24 mm | 19 / 26 | 15.70 mm | 1.1 mm | 13.50 mm | 0.65 mm |
Sea Water Applications etc.
