Admiralty Brass Fin Tubes Manufacturer, Supplier And Exporter

Fin Tubes

Tube Tech produces a complete range of Admiralty Brass Fin Tubes for oil cooler applications. We manufacture Admiralty Brass Fin Tubes fin tubes with excellent dimensional control, for a wide variety of thermal engineering applications. We also manufacture Brass Fin Tubes & Aluminium Brass Fin Tubes as per the requirement.

Brass fin tubes are fabricated in alloy C 44300 / C 27200 & C 68700 to meet the chemical, mechanical and other test parameters of ASTM B 111 / B 359. BS EN, JIS and DIN standards are also available on request.


Tube Dia Wall Thickness Fin Density Fin Dia Fin Depth Root Dia Wall Thickness under Fins
19.05 mm 2.11 mm 19 / 26 / 40 18.80 mm 1.52 mm 16.10 mm 1.30 mm
19.05 mm 1.65 mm 19 / 26 / 40 18.80 mm 1.35 mm 16.10 mm 1.00 mm
19.05 mm 1.32 mm 19 / 26 18.80 mm 1.1 mm 16.60 mm 0.75 mm
19.05 mm 1.24 mm 19 / 26 / 40 18.80 mm 1.1 mm 16.60 mm 0.65 mm
15.87 mm 2.11 mm 19 / 26 15.70 mm 1.35 mm 13.00 mm 1.30 mm
15.87 mm 1.65 mm 19 / 26 15.70 mm 1.25 mm 13.20 mm 1.00 mm
15.87 mm 1.47 mm 19 / 26 15.70 mm 1.25 mm 13.20 mm 0.90 mm
15.87 mm 1.32 mm 19 / 26 15.70 mm 1.1 mm 13.50 mm 0.75 mm
15.87 mm 1.24 mm 19 / 26 15.70 mm 1.1 mm 13.50 mm 0.65 mm
  • For Fin parameters of 22.2 mm, 25.4 mm tube or any other special requirements please contact us.
  • Brass low and medium fin tubes with fin density other than mentioned in the above chart can be produced on request.
  • Brass Fin Tubes are supplied in the “as finned” condition. However, temper annealing OR end annealing of Admiralty Brass Fin Tubes and Aluminium Brass Fin Tubes can be done on request.
  • Brass Fin Tubes are generally produced with desired plain ends, tubes can also be fabricated with intermediate landings upon specific request.
  • Brass Fin Tubes are produced in straight length up to 10 Meters. Bigger lengths can be accommodated on request.
  • Admiralty Brass Fin Tubes are supplied with deburred / smooth ends.
  • All the tubes are hydro tested at desired pressure after finning operation to ensure defect free products.

End Application

Heat exchangers, air condensers and air preheaters, Oil Coolers, process coolers, refrigerant evaporators etc.
